SERIES FEATURES

DARC – ​The Aluminum Cabinet Series

  • □
    Cabinet made of solid aluminum ribs
    with intermediate dampers
  • □
    Gauder Akustik Berlina XPulse drivers
  • □
    Beryllium tweeter, upgradeable to diamond tweeter
  • □
    Symmetrical crossover with ultra-steep filters
  • □
  • TDC Time Delay Control integrated
  • □
    Highly efficient room equalizer
  • □
    WBT NextGen BiWiring Terminal
  • □
    All components from Mundorf, IT, WBT and Clearwater internal wiring
Darc 40 MK II Darc 60 MK II
 Darc 80 MK II
Construction Closed 2-way reference monitor 2½-way floorstanding loudspeaker 2½-way floorstanding loudspeaker
Impedanz [Ohm] 4 4 4
Power handling [W] 140 190 330
Height [cm] 47 / 125 (mit Fuß) 103 116
Width [cm] 24 24 24
Depth [cm] 35 35 35
Weight [kg] 32 / 50 (mit Fuß) 55 65
Darc 100 MK II Darc 200 MK ii Darc 250 MK II
Construction 3-way floorstanding loudspeaker
with 7” double bass system 		3-way floorstanding loudspeaker
with 9” double bass system 		4-way reference loudspeaker with diamond/ mid-high unit
Impedanz [Ohm] 4 4 4
Power handling [W] 490 660 810
Height [cm] 124 132 145
Width [cm] 24 30 30
Depth [cm] 35 45 45
Weight [kg] 72 89 105
Darc 240 MK II Darc 500 MK II
 Darc 750 MK II
Construction 3-way quadruple bass reflex loudspeaker 4-way quadruple bass reflex loudspeaker with diamond /
mid-high unit 		4-way quadruple bass reflex loudspeaker with diamond /
mid-high unit
Impedance [Ohm] 4 4 4
Power handling [W] 1.250 1.250 1.280
Height [cm] 196 197 201
Width [cm] 30 30 30
Depth [cm] 45 45 45
Weight [kg] 138 156 170
Darc Center MK II
 Darc Center Grande
Construction Center speaker for multi-channel speaker system Sophisticated center speaker for multi-channel applications of the highest demands
Impedance [Ohm] 4 4
Power handling [W] 380 780
Height [cm] 33 33
Width [cm] 64 99
Depth [cm] 36 36
Weight [kg] 42 65

Finishes

Natural brushed aluminum

Powder-coated in black

Powder-coated in anthracite

Powder-coated in silver

Powder-coated in white

Intermediate ribs available in

  • ■
  • black
  • ■
    white
  • ■
    silver
  • ■
    gold
